MATERIAL PRESSURE TANK 10 LITERS
DP-K-004-000002DESCRIPTION
TÜV certified material pressure tanks made of stainless steel for conveying liquid media. Capacity: 10 l.
With pressure regulator, quick exhaust valve, float switch with two switching points for refill/ and empty indication and ball cocks for shutting off the lines when refilling the container.
Different variants on request:
Pressure tanks with additional lockable pressure gauge or with Viton are available in all 3 sizes (standard: NBR seal).
Technical Data
Content
10 l
Max. operating pressure
6 bar
Connection
compressed air plug nipple NW 7.2
Diameter
approx. 216 mm
Height
approx. 365 mm
Weight
approx. 4 kg
Float switch
2 switching points
(operation only on safety extra-low voltage)
expand_more Show more...
ACCESSORIES
Further accessories & spare parts on request! Also searched as:
